Our short list of used Optical Metrology and Optical Alignment equipment for sale
Quantities vary. Call or email.
Updated May 1, 2008 - photos will be added during May:
- Autocollimator - Various: Cubic Precision; K&E CN9092-2 with autoreflection objective and autocollimation illuminator - various other Keuffel & Esser models;
Hilger Watts MicrOptic with base TA1-5; Kollmorgen K222 with K10H mount bracket; Leitz Opto-Metric;
Moller Wedel 229-203 AKR 140/40/14.7; Nikon model 6B brightfield or 6D darkfield autocollimator with various Nikon instrument stand options;
Taylor Hobson 112/536-45 and 112/636-375 with autoreflection target.


Angle reading attachment: K&E 71-2302 fits specific K&E / Cubic Precision instruments.
- Clinometer / Inclinometer: Hilger Watts MicrOptic TB95-3 and other Hilger & Watts models.
- Collimator: K&E 9092-4 same as 71-4010 includes incandescent illuminator - available in quantities. Also see target collimator below.
Cross slide for 3.5"x8 instrument mount or stand: K&E 9099-71, same as 71-5080. Electronic Angle Indicator: Old K&E unit - 110V AC powered - analog meter reads + or - 25 secs of arc in 1 sec increments. Model unkwn - sn:169851 - sensing unit not included. Jig alignment telescope: Various 1 axis and 2 axis: Cubic Precision, K&E 71-2062, Taylor Hobson.
Jig transit: Cubic Precision (K&E) 71-1014 featuring 71-1111 optical mic - 71-3250 coincidence level (mounted) and 71-1130 auto-reflection mirror All New Surplus!
- can also be supplied with a 71-1241 right angle auto collimation/projection eyepiece.
Cross level: K&E 71-3205 Stride level: K&E 9099-13B same as 71-3210.
- Coincidence level: Hilger Watts TB9029 1 div=12 sec features a (rotatable) remote sighting prism - small compact unit intended to be affixed to equipment. Line of sight telescope / alignment telescope: Cubic Precision 71-2062 featuring autoreflection objective and autocollimation illumination unit.
Cube mirror: Hilger Watts TP101.3.3 1.5" (unmounted cube reference mirror). Horizontal leveling mirror: Farrand Optical type 113406.
Magnet back mirror: K&E 71-6202 2.5" dia and also K&E 71-6204 4" dia mirror 1/4 wave over 50mm with magnet base surface within 3 sec of parallel to mirror surface. Pentagonal mirror: Hilger Watts TP103 penta prism optical square mil 50260.
Plane mirror; Nikon model D plane mirror 42mm dia.
Plane mirror bench mirror: Hilger Watts TP120-1 3" dia; TP144-1 1.875" dia on 2.875" x 5.375" TP145-1 base; HW model unknown 1.75" dia on 5.375" long base 1 sec tilt =
.000025"; HW model unknown 1.75" x 5.80" mirror on 3" x 8" adjustable sine plate base.

Plumb aligner bracket / vertical telescope mount bracket: K&E 71-5160 to vertically position many 2.25" barrel instruments - features roughing level & precision coincidence level.
Adjustable reference mirror: Davidson Optronics D-615 or D-616; Taylor Hobson 112/4 adjustable mirror reflector 3.7" 94mm dia for 1" post or hor. or vert. table use; Reference mirror, adjustable front surface type 42mm dia mirror for optics laser lab, C/L is 80mm high Mfgr unknown P/Ns: 1248A 36109A Specs/mfgr unknown Highest quality! 2 in stock.

Micro alignment telescope: See above under autocollimator or alignment telescope. Optical metrology equipment. If you don't see it here, call or email with your requirements! Optical micrometer: K&E 71-1112 2 axis optical mic with vernier scale for K&E auto-collimating laser but will fit many other 2.25" dia barrel instruments.
Optical square: Farrand Optical type 88305.
Optical square: Hilger Watts TP103 penta prism optical square mil 50260 - similar in configuration to Davidson D-614.
Optical square: K&E 9092-14 - same as 71-2410 3.5"dia sphere mount type fits 9092- and 71-2020 series instruments, possibly other 2.25" barrel instruments.
Optical tooling bar metrology metrological bar & instrument carriage: Brunson 201 series vertical tooling bar 10ft; Brunson 200 series horizontal tooling bar 10ft 15ft 20ft.;
200DR with digital readout 10ft 15ft 20ft. with 205 series instrumewnt carriages. These optical tooling bars also available for rent. Optical tooling stand: Brunson 230 231 233 series available with 3.5"x8 threads and misc cross slide stages and 273 series coordinate adjuster. Stands available for sale / rent. Penta Prism: Hilger Watts TP103 penta prism optical square mil 50260 - see above under optical square.
Polygon mirror s: Nikon 30 degree 12-sided polyhedral dodecahedral poly prism mirror, Hilger Watts 30 degree 12-sided; 15 degree 24-sided; Davidson 9 degree 100 mil divisions 40-sided model D-633-40; Starrett Webber Croblox 5 degree 72-sided Cr3C2 Now out of production costly 5 degree polygon !


Indexing table: See below under Ultradex. Rotary stage: Precision rotary stage by K&E optical bench or instrument lab applications 6.5" dia ball bearing spindle - model unknown super nice sn:182443 index location to
fractional secs? - Call for more info.
Right angle eyepiece: K&E 71-2220. Table instrument stand: Make/model unknown - For adjustable positioning up/down of a horizontally mounted telescope, collimator, or other 2.250" barrel instrument - range of adjustment is from 6.0" to 12.0 inches off the bench top. Aluminum construction with steel jackscrew. Photo emailed on request.Target collimator: Davidson Optronics D677.Target holder: K&E 71-6410 with optional 71-6420 dial indicator holder - for positioning targets in bores from 16"dia to 68.5" dia. - uses 2.25" dia targets. Telescope or autocollimator mount bracket: K&E 71-5190 4 cone vee-cone type with 3.5"x8 threaded base weight approx 22# or K&E 9099-58 spherical adapter type
(sim. to 71-5180 except with 71-5184 shoe type v-block in place of v-cone) - a less massively heavy fixture than the 71-5190 and without the 3.5" threads.

Tilt collimator: Taylor Hobson 112/9-577
Transit, jig type: Cubic Precision (K&E) 71-1010 / 71-1014 New Surplus! the -1014 is a -1010 featuring 71-1111 optical mic - 71-3250 coincidence level (mounted) and 71-1130 circular auto-reflection mirror - can also be supplied with a 71-1241 right angle auto collimation/projection eyepiece.
}
- Jig Transit Square
- Target; jig transit autocollimator & alignment telescope spherical illuminated type by cubic K&E Brunson.
- Ultradex table, Ultradex rotary indexing tables by AA Gage: 7", 12", 18" sizes, repeatable positioning accuracy of 0.25 arc seconds or better! Various configurations.

Keep us advised of all of your technology equipment requirements by email.
return
to top
Our short list of misc used technology equipment for sale (non-optical).
This equipment is in stock here in Vermont, U.S.A.. Quantities vary. Call or email.
Click here to skip to our used optical equipment list
Updated May 1, 2008:
- Carbon element air filter - portable stainless: Power Products Air Hog AH-C16-1000 8" dia. inlet/outlets. HAZMAT mitigation, etc. New surplus! 4 units.
- Browsers: This list may not be in alpha-sort, please review carefully!
Data aquisition equipment: Acurex AutoCalc; Henze-Movats series 3000 data aquisition or signature analysis module; Crane-Movats Diagnostic System universal diagnostic mainframe; ITT Movats misc equipment.
- Electronic Distance Measuring - EDM equipment, K&E Microranger laser distance measuring set for surveyors/ land surveying
- Explosion proof purge controller: Bebco Rapid Exchange® fully automatic gas purging system for control of explosion-proof enclosure. Model 2002-FA-CI. Type X.
Removed from never installed/never used gas detection equipment. New Surplus! 3 in stock.
- MIDAS Technology model HGRS-IV-P Hot gas rework station, sn: 9744047. This unit will do things that a solder reflow station cannot. Call!
- Indexing tables: See Ultradex with photos on our optical equipment list.
- Lab mixer: Processall 4H/V, 4 liter lab size mixer, steam jacket, vacuum de-airing ports.

- Metallurgical microscope- metallograph: Lietz MM5 (vintage), Unitron RMM rollscope. Photos emailed on request.
- Misc items:
Large lot of cutters (hobbs) for bandsaw blade/ sawblade manufacturing.
3M Scotchcal reflective film for heat transfer application to road signs, highway signs and railroad railyard signs, railcars, etc.. Various widths/colors. New Surplus.
- Optical Metrology / Optical Alignment: Call or email with your requirements! Click here to skip to our used optical equipment list
- Photo etch / resist dispensing system for semicon circuit board prototyping production: Now Technologies 10 liter stainless steel capacity liquid chemical handling / dispensing system NPD-310-1 NPD-210-1 & NOWPAK LMO-6 level monitor system - New Surplus in factory carton.
- Pump - Rotary lobe for liquid or slurry handling: Alfa Laval Flow SRU-4 316L stainless steel sanitary process or transfer pumps for pharmaceutical, food, beverage, cosmetics, etc.
with 5hp 230/460V motor, U.S.A. 3A and CIP qualified. Modern, energy efficient. Never used - New surplus in crate!
- Research Radiometer / light meter: International light IL1700, less probes. Excellent. Photos emailed on request.
- Relative Humidity sensor - Smart RH sensor: Graftel 9203, large quantity available.
- Smart Temperature sensor: Graftel 9202, for nuclear plant standards etc - large quantity available.
- Rotary and X-Y stage base - Leitz L227 - 200mm dia table permits inert gas or vacuum feed to the specimen chamber (bell jar chamber cover not included).
- Thermal Forcing system: Temptronic Thermostream temperature forcing system type TP0412A-TL1-60. sn# 9010495 code 3. For thermal testing/cycling circuit boards, electronic components, adhesives, resins, composite structural materials, plastics, instrumentation, other electrical, electronic/mechanical devices/materials.
- Ultradex table, AA Gage Ultradex rotary indexing tables by AA Gage: 7", 12", 18" sizes, repeatable positioning accuracy of 0.25 arc seconds. Various configurations.
- Vibration analysis - spike energy test: IRD Mechanalysis TEC Smart Meter FS; also types 820 - 838 - 890 vibration analyzer equipment for nuclear plant standards etc..
Keep us advised of all of your technology equipment requirements by email.
